Durable Flexible Stainless Steel Ferruled Mesh With Ringent And Closed
Product Parameter
| Application | Woven Wire Mesh |
| Hole shape | Square |
| Surface treatment process | polishing |
| Length | Requirement |
| Material | Stainless Steel Wire |
| Weave Style | Plain Weave/Twill weave |
| Color | Silver, Black, etc |
Feature
1). High strength, strong toughness, free-angles curving and fold, easy for transportation and installment.
2). Anti-corrosive, resist the rust, can be repeated use.
3). Resists chewing by rodents and other pests (tensile strength approximately 100-110,000 PSI)
4). Can bear the heavy snow and the gale very much.
5). Without toxic material, safety, environmental protection.
Specification
Material:
stainless steel type 304, 304L, 316, 316L
Structure:
7x7 and 7x19
Standard cable diameter:
1/8", 3/32", 1/16", and 3/64"
Standard mesh opening size:
1"x 1", 1-1/2"x1-1/2", 2"x2", 3"x3", and 4"x4"
| The list of Stainless Steel Wire Rope Mesh (knotted mesh)Material made of S.S 304 or 316 and 316L |
| Code | Wire Rope Construction | Min. Breaking Load
(KN) | Wire Rope Diameter | Aperture |
| Inch | mm | Inch | mm |
| YT-3210 | 7x19 | 8.735 | 1/8 | 3.2 | 4" x 4" | 102 x 102 |
| YT-3276 | 7x19 | 8.735 | 1/8 | 3.2 | 3" x 3" | 76 x 76 |
| YT-3250 | 7x19 | 8.735 | 1/8 | 3.2 | 2" x 2" | 51 x 51 |
| YT-2410 | 7x7 | 5.315 | 3/32 | 2.4 | 4" x 4" | 102 x 102 |
| YT-2476 | 7x7 | 5.315 | 3/32 | 2.4 | 3" x 3" | 76 x 76 |
| YT-2450 | 7x7 | 5.315 | 3/32 | 2.4 | 2" x 2" | 51 x 51 |
| YT-2076 | 7x7 | 3.595 | 5/64 | 2.0 | 3" x 3" | 76 x 76 |
| YT-2050 | 7x7 | 3.595 | 5/64 | 2.0 | 2" x 2" | 51 x 51 |
| YT-2038 | 7x7 | 3.595 | 5/64 | 2.0 | 1.5" x 1.5" | 38 x 38 |
| YT1676 | 7x7 | 2.245 | 1/16 | 1.6 | 3" x 3" | 76 x 76 |
| YT-1650 | 7x7 | 2.245 | 1/16 | 1.6 | 2" x 2" | 51 x 51 |
| YT-1638 | 7x7 | 2.245 | 1/16 | 1.6 | 1.5" x 1.5" | 38 x 38 |
| YT-1625 | 7x7 | 2.245 | 1/16 | 1.6 | 1" x 1" | 25.4 x 25.4 |
| YT-1250 | 7x7 | 1.36 | 3/64 | 1.2 | 2" x 2" | 51 x 51 |
| YT-1238 | 7x7 | 1.36 | 3/64 | 1.2 | 1.5" x 1.5" | 38 x 38 |
| YT-1225 | 7x7 | 1.36 | 3/64 | 1.2 | 1"x1" | 25.4x25.4 |
| YT-1220 | 7x7 | 1.36 | 3/64 | 1.2 | 4/5"x4/5" | 20x20 |
Application
· Animal Enclosure mesh
· animal cages, bird netting
· Agriculture
· Residential
· Sports
· Fall Security
· Ocean Park and other similar environments
· garden decoration and construction and renovation
